Noise Data (All Areas)

General Noise

Most us experience a variety of sound on a daily basis. According to the Cambridge Dictionary, noise is defined as a sound that is unwanted, unpleasant, or loud.

Noise is not only about how loud the sound is. There are a complex set of factors that drive annoyance both based upon the noise itself and what that noise means to us. A dripping tap is mostly quiet, but it’s repetitive beat can be annoying. A mosquito’s buzzing is also quiet, yet it is high pitched.

Sounds rarely occur in isolation. It is when we build a combined picture of all of the day-today sounds such as traffic and wind, that we start to identify noise. Certain noises, such as a siren, can be easily heard above the day-to-day sound. Other noises may only be heard when the background level is lower, such as during the night. These principles also apply to aircraft. Whilst the sound level will vary depending on your location, what that sound means to us individuals will drive our response to the resulting noise.

East Midlands Airport Noise Data

To understand the noise impact on the local community, the airport has a number of fixed or temporary noise monitors deployed in the local area, generally under or near flight paths. The monitors detect and record the noise levels 24 hours a day, 7 days a week to ANOMS.

A ‘noise event’ is created when the monitor detects noise exceeding the background or local noise level for a noticeable amount of time. This could be due to any number of factors, be it nearby birds, cars or an aircraft. By continuously monitoring the noise level and integrating data from Air Traffic Control (ATC) our systems work to determine if the noise event was generated by an aircraft, or another source. Only events reported as aircraft noise events are reported in our statistics.

The data collected by all of our fixed noise monitors is presented in the dashboard below.

Choose a noise monitor location in the top left hand corner to get started.  See our ‘How we manage noise’ page (under the “What are we doing” heading) for more information about noisy aircraft penalties.  A number of our noise monitors positioned directly below the flight path are used for fining aircraft on departure and the noise limits are calibrated with respect to the height and distance of the runway to the monitor location.

The dashboard is automatically updated every month and you can access data from previous months using the drop-down. A comprehensive list of aircraft types can be found here.

View Fullscreen
Posted on

Find a particular flight

Introduction

WebTrak is our online flight tracker which provides the aircraft flight number, aircraft type, its height and track.

We also show aircraft which do not operate from our airport. You can see aircraft arriving and departing, sometimes in a holding pattern, operations from other airports nearby, as well as the data direct from our fixed and mobile noise monitors.

WebTrak uses data taken directly from air traffic control (ATC) radar, this is the same data that ATC use to safely manage aircraft in the sky. It is fed directly into the Airport Noise Monitoring and Management System (ANOMS) which powers the flight tracking systems.

Please note: A delay of up to 6h is applied to the replay of ‘live’ data to ensure all data is presented as accurately as possible.

How to use WebTrak

Showing where the help can be found (top left) in webtrak, where historical data can be found (bottom left) and how to move time (slider at bottom)

WebTrak, allows you to both investigate flights above your area in near real-time as well as investigating historical data. There is lots of online help contained in the tool (available through the menu on the left hand side of the screen) to help you understand the icons and method of operation. But to summarise some of the key features, you can:

  • Investigate a specific flight that might have caused a disturbance,
  • Investigate flights from the the busiest part of a day,
  • Discover where a flight was going or where it came from
  • Analyze the proximity of flights to your location by dropping a pin on the map.

Sometimes the tool will display flight routes or rainfall layers. These sorts of overlays provide a great visual tool for analysing flight corridors or understanding adverse weather.

You can also make a complaint about the flight, which will be sent through to us for review. This method helps us because we can immediately identify the aircraft that caused the disturbance.

I can’t see the flight that disturbed me

Webtrak takes a feed directly from Air Traffic Control (ATC) and whilst we aim to display all flights, you may notice that some are missing. This could be due to a number of reasons including:

  • If it was a military, police or civil protection flight
  • If the aircraft was carrying a Government Official or Head of State
  • If the aircraft was operating to/from another airport
Posted on

Arrivals and Departures

Wind and Runway Direction

To ensure a safe take-off and landing, aircraft depart and arrive into the wind. On take-off, this helps produce the lift required to get airborne and landing into the wind enables a slower speed over the ground. The weather and wind direction can change and therefore the direction that the aircraft are arriving and departing may change to ensure the safest conditions to operate.

Air Traffic Control manages the runway direction for the safest aircraft operations. This includes consideration of the wind at ground level, 1000ft, and 2000ft, as well as the forecasted weather. Local weather forecasts only display wind strength and direction at ground level and this can differ at higher altitudes. Therefore local weather forecasts are not always a reliable indicator of the likely direction that aircraft will be operating.

When the wind is blowing from west to east, the airport will operate in a westerly direction, known as “westerly operations” and the reverse during “easterly operations”. Experience of operations at East Midlands Airport shows an average of over 75% of operations, each year, are westerly and the remaining operations in an easterly direction. The approximate 75/25% split is an annual average and there are months with a much higher/lower proportion of westerly/easterly operations. An image demonstrating the direction of operations can be seen below:

Arrivals

Flight paths for arriving aircraft follow broadly similar patterns, unlike departures which are much more defined. The flight paths ensure separation from other air traffic and avoidance of adverse weather when necessary. This means that there may be variation in airport arrivals at different times of the day.

Aircraft arriving into East Midlands Airport are transferred from the NATS area control centre to the Airports ATC approach controller between 25-35nm (nautical miles) away from landing. They are then instructed where to fly by the Air Traffic Controllers, where they are directed towards their final approach before landing. When established on final approach to East Midlands Airport, aircraft are transferred from the approach controller to the tower controller before landing.

To minimise the noise of approaching aircraft for communities near arrival paths, a ‘Continuous Descent Approach’ (CDA) is used when possible. Instead of a traditional descent whereby the aircraft reduces altitude in a stepped manner (similar to walking downstairs), they glide at a more constant rate (like an escalator). This keeps aircraft at a higher altitude for longer, minimising noise for local residents before an aircraft joins the ILS (the red shaded area in the image below), as well as providing benefits for fuel efficiency and reducing emissions. Operating a CDA is not always possible due to several factors such as congested airspace or adverse weather conditions which need to be avoided. With the East Midlands Future Airspace project, we plan to facilitate changes that will make CDA easier to deliver. Compliance with this procedure is reported on here and you can find out more about arrivals at East Midlands Airport in the following video.

Please note this video is orientated as if you are positioned on the North of the airfield, looking towards the South.

Departures

Departing aircraft move on the ground from their parking stands to the runway using taxiways. At the runway, they then await clearance from Air Traffic Control (ATC) to take-off. The weight of a departing aircraft can vary due to the amount of fuel, passengers, luggage, or cargo, and there can be a difference in the noise generated as the aircraft accelerates along the runway to become airborne.

Depending on the aircraft’s destination, the departure will fly one of a number of departure routes (known as Noise Preferential Routes or NPRs). These routes are flown to minimise the overflight of local communities, whilst ensuring separation with other departures and surrounding air traffic, as well as optimising routing to the destination. The NPRs can be seen below. You can find out more about East Midlands Airport departures in the following video.

Please note this video is orientated as if you are positioned on the North of the airfield, looking towards the South.

Aircraft must remain within the NPR until they reach a minimum altitude of 5,000ft, after which ATC can provide a more direct routing to the destination. For safety reasons, ATC may sometimes provide instruction to an aircraft to exit the NPR earlier to avoid adverse weather or other air traffic. Compliance with this procedure (known as track keeping) is reported on here.

Posted on

Unusual Operations

Unusual Operations

From time to time you may notice an unusual aircraft operation at or around the airport. Below are a number of examples of unusual operations that you may see at East Midlands Airport.

Go-arounds or missed approaches

A go-around, or missed approach, can occur for many reasons such as, an obstruction on the runway preventing the aircraft from landing safely, a change in the wind conditions or that the aircraft cabin is not secure for landing. When coming into land, if a go-around is initiated, the pilot will apply thrust to climb straight ahead and then either turn left or right. Because a go-around can occur at any stage of the approach, the climb and turn could occur before or after reaching the runway. The exact path taken by an aircraft going around will be dependent on surrounding air traffic, the weather, the direction of operation and the point at which it is initiated.

The aircraft will take a wide orbit around the airport and then Air Traffic Control will then position the aircraft to make a second approach to the runway to land. This may mean that aircraft performing a go-around could overfly areas they do not normally at potentially lower than expected altitudes. Go-arounds are a rare occurrence at East Midlands Airport.

You can find out more by watching this video:

An example of a go-around on Runway 27 (Westerly Operations) can be seen below. As you can see the aircraft took a left turn and orbit around to re-establish for a second, successful, approach on to Runway 27:

Aircraft Holding

On occasion, often at busy times or during adverse weather, it will not be possible for aircraft to approach and land at East Midlands Airport without having to be held for a short period of time. This takes place in fixed oval pattern known as a stack or hold.

East Midlands Airport has two holding stacks; one called ‘PIGOT’ which is located South of Leicester and the second, ‘ROKUP’ is located Northwest of Nottingham. The stacks were located here in 2005 after an extensive period of airspace consultation in 2004 and CAA approval of the change. The minimum altitude of aircraft in the stack is 8,000ft and is set to keep noise on the ground as low as possible. The holding stacks are not used very often at East Midlands Airport as aircraft are usually able to land without delay.

You can find out more by watching this video:

Military Flights

On occasions, military aircraft use East Midlands Airport. As military aircraft sometimes need to divert to civilian aerodromes, it is important that pilots are familiar with the procedures at civilian airports, as they will differ from military bases. Due to the nature of their purpose, these aircraft, in particular fighter jets, are not designed with any noise-reducing features so their noise profile can be particularly loud. We are limited in our ability to mitigate against the noise impacts of these types of aircraft.

Helicopter Operations

Most helicopters operating at East Midlands Airport operate under ‘Visual Flight Rules’ and do not fly the Noise Preferential Routes (NPRs) when departing as commercial jet aircraft do. Similarly, helicopters do not arrive in the usual patterns seen with commercial jet aircraft. The pilot navigates using “visual” ground-based features such as roads and rivers etc. Examples of helicopter operations include Air Ambulances as well as helicopter operators passing through East Midlands Airport airspace.

Air Charters

Occasionally you may see some unusual freight aircraft. An example of which is the AN-124. The AN-124 is one of the largest aircraft in the world, specifically designed for carrying heavy or bulky loads. Equipped with a high volume of cargo capacity, drive-on loading ramps and a variety of built-in freight handling equipment. These are specialist aircraft used for carrying abnormal cargo which do not fit in the regular cargo aircraft seen at East Midlands Airport.

Posted on

Night Flights

Night Flights

As the world becomes more connected, there is a growing demand for air transport, which includes passenger and cargo connectivity around the world, into and out of different time zones. Not only does this make it easier for people to travel for holidays and to see friends and family, but it also helps businesses and the local economy by providing transportation links for time critical goods and services.

East Midlands Airport is a nationally important cargo hub, and is the UK’s largest express air cargo airport. It is a significant base for three of the major global integrated freight operators, DHL, UPS, and FedEx, handling over 400,000 tonnes of cargo every year. Due to a combination of demand for goods from markets with different time zones (such as Asia), ‘next day delivery’ and other logistical practices night flights are essential for global trade.

We recognise that night-time noise from aircraft operations is often the most intrusive. At East Midlands Airport, the night period is defined as 23:00-07:00. Our night noise controls are intended to strike a balance between the economic and social benefits a thriving airport provides and the disturbance which can be caused by night flights.

Whilst night flights aren’t typically any louder than daytime operations, the background or ambient noise level can be lower, meaning an aircraft is more easily heard.

East Midlands Airport has procedures in place to minimise the disruption caused by night flights. These procedures have evolved through consultation with local communities as part of the Noise Action Plan process.

  • To encourage airlines to fly as quietly as possible at night, we operate a noisy aircraft penalty. Using our noise monitoring system, we measure the level of noise generated by each departing aircraft. Noise is measured by monitors positioned at fixed points beneath the departure flight paths. Money raised from noisy aircraft penalties is donated to the East Midlands Airport Community Fund. We report all instances of breaches to the Airport Consultative Committee.
  • East Midlands Airport prohibits airlines from scheduling and operating the noisiest aircraft types at night 23:00 – 07:00. These are classified as having a Quota Count (QC) of 4, 8 or 16. Any late running aircraft of these types are prohibited from operating during the night period, unless there are exceptional circumstances such as live stock or perishable cargo. Should these operations occur under exceptional circumstances, the operator would also pay a surcharge to the Airport Community Fund.
  • We operate within an agreed planning condition set by North West Leicestershire District Council, so that our ‘night noise envelope’ (based on the 55dB LAeq 8-hour night contour) will not exceed an area of 16km2. The airport is operating well within this limit.

You can find more information within the ‘How we manage noise’ section.

Posted on

Training Flights

Training Circuits

The training of aircrew is an essential requirement for any airline, and whilst much training is now undertaken using flight simulators, some flying is mandatory to meet Civil Aviation Authority (CAA) standards. The final part of a pilots training is to complete a number of ‘training circuits’ which repeat the take-off and landing procedures. This type of operation is sometimes completed at East Midlands Airport.

Training circuits are operated under visual flight rules and are within visual range of the Airport and the Air Traffic Controller. Training flights are unable to follow the Noise Preferential Routes (NPRs) that are usually followed by departing aircraft as this would likely extend aircraft beyond visual range of the tower. Also, as the aircraft is returning immediately to the airport, these flights do not climb as high as departing aircraft do. Training flights generally climb to 2,000ft above sea level.

These types of training flights are often referred to as ‘Touch and Go’ where the aircraft does not come to a complete stop after landing on the runway, but adds thrust to depart once again. These circuits can be completed up to seven times per student. Because of the nature of training flights, each pilot needs to practice several circuits and hence these circuits can be repetitive. The nature of these circuits can follow a broadly similar flight pattern. Therefore, aircraft can be overflying the same location regularly, and can overfly areas that are not usually overflown by arriving or departing aircraft.

You can find out more by watching this video:

Light Aircraft Training

At East Midlands Airport there is a locally based flying club which offers trial flights, trial flying lessons and flight training for the Private Pilot’s Licence (PPL). These light propellor aircraft also operate under visual flight rules and do not follow the same routings as commercial jet aircraft.

Minimising Disturbance

We recognise that training flights, while enabling the training of air crew, can be particularly disturbing to local communities, so we are committed to minimising the impact of training flights.

In response to community feedback and as part of our Noise Action Plan, we have introduced a wide range of restrictions on training flights. These restrictions include:
– Only permitting training by locally based operators, regular users of the airport, or non-jet aircraft below 5,700kg maximum take-off weight (MTOW).
– Not permitting training on Saturdays, Sundays, and UK public holidays except by non-jet aircraft below 5,700kg MTOW.
– From 1 January 2024, we now only schedule training flights between 08:00 and 12:00 and between 14:00 and 18:00 on weekdays, excluding public holidays.

The restrictions in place are relevant to the noisier jet engine aircraft circuit training. Smaller and quieter propellor aircraft may operate different training flights and routes at East Midlands Airport.

More detail is available within the full Noise Action Plan here.

Posted on

Typical flight paths

Arriving and Departing Aircraft

Every major commercial airport typically has set flight paths for departing aircraft from their runways. These are in place to maintain safety, and whilst safety is always the number one priority, these routes are designed to minimise environmental impacts as much as possible in terms of fuel burn, emissions and noise. However, airspace congestion and local weather, such as thunderstorms, may result in a large spread in flight paths. Arriving aircraft follow broadly similar patterns, which are not as defined as the flight paths for departing aircraft. Aircraft are directed by ATC to a position where they turn onto a runway heading (the direction of the runway that the aircraft will land on) before making its final approach. At East Midlands Airport there is an Instrument Landing System (ILS) that guides the airport during its final approach to the runway.

The typical flight paths used at East Midlands Airport are shown in the following interactive tool for both westerly and easterly operations. All data has come directly from our Aircraft Noise and Operations Monitoring System (ANOMS), which receives flight data from air traffic control radar. This system is operational 24 hours a day, 7 days a week, continuously tracking and recording aircraft flights to and from the airport. Flight tracks are recorded from radar data centred at the airport. The reason you will see radar tracks ending is because the extent of our radar coverage is 40nm (nautical miles). The graphic below shows arriving aircraft as red tracks with departing aircraft shown as green tracks.

Posted on

Frequently asked questions

Here’s a compilation of some our most frequently asked questions and we’ll endeavour to update this list as new questions emerge:

Who is responsible for managing aircraft noise?

The policy framework and guidelines for managing noise are set at a national and international level but as the airport operator, it is our responsibility to manage noise locally around the airport. We do that by working closely with Air Traffic Control, Airline Stakeholders, the Airport Consultative Committee, the CAA, and the Government.

What is circuit training?

Training is an essential requirement for all airlines, and while much training is undertaken in simulators, some actual flying is necessary to meet the guidelines of the Civil Aviation Authority (CAA). Circuit training is the act of repetitive take-offs, approaches and landings at the same airport. It is an essential training technique to ensure the pilot is fully trained in all aspects of a departure and approach procedures. However, aircraft flying training circuits are unable to follow the normal Noise Preferential Routes (NPRs) as they must stay within the controlled airspace of the airport and are required to maintain visual contact with the runway.

We are very aware of the potential disturbances that training circuits can cause, and to minimise these disturbances, East Midlands Airport imposes several control measures. More information can be found on the “How does the airport operate?” section of this portal.

Can I get a noise monitor installed at my home?

Noise monitors are deployed in the local area to monitor and record noise from both aircraft and background sources. This allows us to evaluate trends and make comparisons between noise levels at different locations. The majority of our monitors have been in their current location for an extended period of time and you can see the location of these monitors within our noise report on this portal.

Whilst it is difficult to re-locate these long-term monitors, the airport has access to a short term monitoring program where noise monitors can be located in areas for short periods. The monitors within this program are typically used to collect data for a study for to further understand a specific issue in a certain area. The monitors are placed in response to requests made through the Consultative Committee from local Parish Councils. However, requests from local residents are taken into considerations as part of the wider monitoring program.

Please see our Noise Monitor Policy below.

EMA-Policy-for-Mobile-Community-Noise-Monitor-Deployment

What affects the selection of runways on any given day? And why does the selected runway differ to the wind forecast?

The most common factor is wind direction as aircraft typically take-off and land into wind. However it is not only the wind at ground level that must be considered, but also the wind at altitude, which can often be substantially different. It is for this reason that the local weather forecast may suggest a different wind direction to that in which the airport is operating.

In addition, factors such as the traffic flow, local airport works and thunderstorms may restrict or temporarily alter how runways are used at airports.

What are minimum flying heights for aircraft?

For typical arrival and departure operations to/from airports there are no minimum flying heights although pilots are encouraged to fly using the optimal noise abatement procedures, which are designed to keep the aircraft higher for longer to reduce noise.

Outside of the usual arrival/departure operations, in most regions of the world there are altitude restrictions which pilots must not descent below when they are overflying cities, towns or populous areas. Typically this is 1,000 ft or when over other non-populated terrain 500 ft. However exceptions do apply, for example:

  • Military, police, medical and search and rescue operations
  • in situations where the weather requires lower flying
  • for helicopters flying within specified access lanes
  • where the aircraft is engaged in air work for which the operator has a permit (such as media helicopters)

Planes are flying lower than they used to

Some planes are much larger than others, and the size difference can make a person perceive they are closer, when they are at the same height as previously. Whilst factors such as altitude and temperature can sometimes affect the performance of planes as they take off; for example, hot weather can affect a plane’s ability to climb as quickly as they do in the cooler winter months.

Pilots fly where they want to:

Commercial aircraft that carry passengers and/or cargo are typically operating within controlled airspace managed by Air Traffic Control (ATC). ATC act as a coordinator to ensure aircraft are safely separated and efficiently directed towards their destination. You can view where aircraft fly through this portal or by using our flight tracking tools.

Flight paths have changed:

Aircraft departing from East Midlands Airport are required to follow one of five initial flight paths, known as Noise Preferential Routes (NPRs) until they reach the required minimum altitude of 5,000ft. It is at this point that the aircraft can be released from the NPR onto a more direct heading to its destination by NATS. Our NPRs are designed to minimise the number of people impacted by aircraft noise by diverting aircraft away from some of the more built-up areas and have been in place since early 2000’s.

It is not always possible to keep aircraft contained within these NPRs. Adverse weather conditions or the presence of other air traffic may require an aircraft to deviate from the NPR before reaching the minimum required altitude. These diversions are monitored regularly by the airport, and the results are published online every month.

Unlike departures, there are no predetermined routes for arriving aircraft. The only area where we can predict the flight path for arrivals is the final approach, the 8 to 10 miles of flight prior to landing where aircraft follow the guidance from the instrument landing system or ILS.  Although typically arrival tracks do tend to concentrate within a similar area, ATC have to be able to direct arrivals anywhere within controlled airspace to maintain safety and efficiency.
